Craftsman’s 24-inch manual snowblower offers reliable winter performance, and understanding its components is key to efficient operation.
Accessing diagrams and manuals, like model 247.888160, ensures proper maintenance and repair.
This snowblower, including models 247.881732 and 536887251, provides powerful snow removal.
Utilizing resources like eReplacementParts, with its detailed parts lists, simplifies troubleshooting and upkeep.
Whether you need to identify parts for model SB410 or CMXGBAM1054541, this guide will help you maintain peak performance throughout the winter season.
Overview of the 24-Inch Model
The Craftsman 24-inch manual snowblower is designed for medium to large driveways, efficiently handling substantial snowfall. Its two-stage system incorporates a robust auger to pull snow into the machine, followed by a high-speed impeller to discharge it through the chute.
This model, often referenced by numbers like 247889571 and 247.888160, boasts a 6.5 horsepower engine, providing ample power for various snow conditions. The 24-inch clearing width reduces the number of passes needed, saving time and effort during snow removal.
Key features include adjustable skid shoes for optimal ground clearance and a manual recoil start. Understanding the parts diagrams, readily available online, is crucial for maintenance and repair, ensuring years of reliable service. It’s a powerful and practical solution for winter weather.
Importance of the Owner’s Manual
The owner’s manual for your Craftsman 24-inch snowblower is an indispensable resource, containing vital information for safe and effective operation. It details crucial pre-operation safety checks, ensuring you understand potential hazards and preventative measures.
Beyond safety, the manual provides detailed instructions on maintenance procedures, like oil changes and shear pin replacement, extending the lifespan of your machine (models 247.881732, 536887251). Accessing model-specific information, such as for SB410 or CMXGBAM1054541, is simplified through the manual.
Furthermore, it aids in troubleshooting common issues, like starting problems or auger malfunctions. Utilizing parts diagrams referenced within the manual, alongside resources like eReplacementParts, streamlines repairs and ensures you order the correct components (247.888160).
Understanding Key Components
Craftsman’s 24-inch snowblower features a 6.5 horsepower engine, robust auger and impeller systems, and a drive system—all vital for efficient snow removal.
Detailed diagrams, like those for model 247889571, illustrate these components, aiding in maintenance and repair, ensuring optimal performance throughout winter.
Engine Specifications (6.5 Horsepower)
The Craftsman 24-inch snowblower is typically equipped with a reliable 6.5 horsepower engine, providing ample power for tackling moderate to heavy snowfall conditions. This engine size strikes a balance between performance and fuel efficiency, making it suitable for most residential snow removal needs.
Understanding the engine’s specifications is crucial for proper maintenance. Regular oil changes, using the manufacturer-recommended grade, are essential for longevity. Referencing the owner’s manual, such as for model 247.888160, provides detailed guidance on engine care.
Proper engine maintenance, including spark plug checks and air filter cleaning, ensures consistent starting and optimal power output. Utilizing OEM parts, found through resources like eReplacementParts, guarantees compatibility and performance.
Auger System Details
The Craftsman 24-inch snowblower’s auger system is central to its snow-clearing capability. This system utilizes a rotating, spiral-shaped auger to gather snow and feed it into the impeller housing. The 24-inch width allows for efficient clearing of pathways and driveways.
Understanding the auger’s components, including the shear pins, is vital for safe operation and maintenance. Shear pins are designed to break under excessive stress, protecting the engine and auger from damage. Replacement parts, identifiable through diagrams for models like 247889571, are readily available.
Regular inspection of the auger blades for wear and damage is crucial. Maintaining sharp blades ensures optimal snow-throwing performance. Refer to the owner’s manual for detailed instructions on auger maintenance and safety procedures.
Impeller System Details
The Craftsman 24-inch snowblower’s impeller system takes snow gathered by the auger and forcefully expels it through the discharge chute. This system consists of a high-speed rotating impeller housed within the snowblower’s casing. Proper impeller function is essential for achieving the desired throwing distance and clearing power.
Maintaining the impeller’s integrity is crucial for optimal performance. Inspecting the impeller blades for wear or damage, and ensuring they are securely fastened, is vital. Accessing parts diagrams, such as those for model 247.888160, aids in identifying replacement components.
Regularly checking the discharge chute for obstructions ensures efficient snow expulsion. Refer to the owner’s manual for detailed instructions on impeller maintenance and safety precautions.
Drive System Mechanics
The Craftsman 24-inch manual snowblower’s drive system provides the power to propel the machine forward, enabling efficient snow removal. This system typically utilizes a belt-driven mechanism connecting the engine to the wheels. Understanding its mechanics is key to diagnosing and resolving drive-related issues.
The drive system’s functionality relies on a properly tensioned belt and intact drive components. Inspecting the belt for wear, cracks, or looseness is crucial for maintaining optimal performance. Parts diagrams, like those available for model SB410, assist in identifying replacement belts and related hardware.
Referencing the owner’s manual provides detailed instructions on drive system maintenance and adjustment. Ensuring proper lubrication and alignment contributes to smooth operation and extends the system’s lifespan.
Parts Diagrams and Identification
Accessing online parts diagrams (model 247889571) is vital for identifying components.
eReplacementParts offers detailed visuals for easy Craftsman snowblower maintenance and repair.
Understanding exploded views simplifies locating common replacement parts, ensuring accurate ordering using model numbers like 247.888160 and SB410.
Accessing Online Parts Diagrams (Model 247889571)
Locating the correct parts diagram for your Craftsman 24-inch snowblower, specifically model 247889571, is now easier than ever thanks to readily available online resources. eReplacementParts.com provides a comprehensive library of schematics, allowing you to visually identify each component of your snowblower.
These diagrams are invaluable when undertaking repairs or routine maintenance. They clearly illustrate the assembly of the snowblower, making it simple to pinpoint the exact part you need. Simply navigate to the website and enter your model number to access the corresponding diagram.
Furthermore, many retailers offering Craftsman parts also provide access to these diagrams on their websites. Utilizing these resources ensures you order the correct replacement parts, saving you time and frustration. Always verify the diagram matches your specific model for accuracy.
Identifying Common Replacement Parts
Maintaining your Craftsman 24-inch snowblower often requires replacing worn or damaged parts. Shear pins are frequently needed, protecting the auger from damage during obstructions. Drive belts are also common replacements, ensuring proper power transfer to the wheels.
Auger blades experience wear and tear and may require periodic sharpening or replacement. Scraper bars, which clear snow from the discharge chute, also benefit from regular inspection and replacement; Identifying these parts quickly is crucial for minimizing downtime.
Parts retailers specializing in Craftsman snowblowers offer detailed listings and diagrams to help you locate the correct components; Knowing your model number (like 247.888160) is essential for accurate ordering and ensuring compatibility.
Understanding Exploded Views
Exploded views are invaluable for visualizing the assembly of your Craftsman 24-inch snowblower. These diagrams depict each component’s precise location and relationship to others, simplifying repairs and maintenance. Resources like eReplacementParts provide detailed exploded views for models like 247889571.
Understanding these views allows you to identify parts quickly and accurately, even without prior mechanical experience. They illustrate how components fit together, aiding in reassembly after disassembly. This is particularly helpful when tackling complex repairs or replacements.
By studying the exploded view, you can anticipate potential challenges and ensure you have all necessary tools and parts before starting a project. Utilizing these diagrams streamlines the repair process and minimizes frustration.
Maintenance and Repair
Regular maintenance, including oil changes and shear pin replacements, ensures optimal performance of your Craftsman 24-inch snowblower.
Refer to the owner’s manual for schedules and guides.
Belt replacements and troubleshooting common issues, like starting problems, are simplified with access to diagrams and parts lists from resources like eReplacementParts.
Regular Maintenance Schedule
Maintaining your Craftsman 24-inch snowblower requires a consistent schedule to ensure reliable operation. Before each use, inspect the auger and impeller for damage, and check all bolts and fasteners for tightness. Regularly examine the shear pins – having spares on hand is crucial for quick repairs.
After every five to ten hours of operation, or at the start of each season, change the engine oil. This prevents wear and tear on vital components. Inspect the drive belt for cracks or fraying, replacing it as needed. Clean the snowblower thoroughly, removing any accumulated snow and debris.
Annually, inspect the fuel lines and carburetor for any signs of deterioration. Stabilize the fuel during storage to prevent gumming. Following this schedule, alongside referencing your owner’s manual (like 247.888160), will maximize the lifespan and performance of your snow removal equipment.
Oil Change Procedures
Changing the oil in your Craftsman 24-inch snowblower is vital for engine health. Begin by warming the engine briefly, then disconnect the spark plug wire for safety. Locate the oil drain plug, typically found on the lower part of the engine, and position a drain pan underneath.
Remove the drain plug and allow the old oil to drain completely. Once drained, reinstall the plug securely. Next, locate the oil fill cap and carefully pour in the recommended oil type and quantity – consult your owner’s manual (e.g., 247.888160) for specifics.
Check the oil level using the dipstick, ensuring it falls within the designated range. Properly dispose of the used oil at a recycling center. Regular oil changes, following these steps, will contribute to the longevity and efficient operation of your snowblower.
Shear Pin Replacement
Shear pins are designed to protect your Craftsman 24-inch snowblower’s auger system from damage. When the auger encounters a hard object, the pin breaks, preventing costly repairs. To replace a broken shear pin, first disconnect the spark plug wire for safety.
Locate the shear pin – often found connecting the auger to the gearbox. Use a punch and hammer to drive out the broken remnants of the old pin. Insert the new shear pin, ensuring it’s properly aligned, and secure it with the retaining clip or bolt.
Refer to your model’s parts diagram (like those for 247.881732) to ensure you’re using the correct replacement pin. Always keep spare shear pins on hand, as they are consumable items, and crucial for continued operation.
Belt Replacement Guide
Replacing the drive belt on your Craftsman 24-inch snowblower restores proper auger and drive system functionality. Begin by disconnecting the spark plug wire for safety. Access the belt by removing the belt cover, often secured with bolts or clips.
Note the belt’s routing before removal – a diagram (referencing models like 247.888160) can be invaluable. Carefully remove the old belt, then install the new one, ensuring it’s seated correctly in all pulleys and grooves.
Double-check the routing against your diagram and reinstall the belt cover. Proper belt tension is crucial; adjust if necessary. Utilizing OEM parts ensures compatibility and optimal performance, maintaining your snowblower’s efficiency.
Troubleshooting Common Issues
Common problems with your Craftsman 24-inch snowblower include starting issues, auger malfunctions, and drive system failures.
Referencing model numbers like 247.881732 aids diagnosis.
Utilize online resources and diagrams (e.g., 536887251) to pinpoint the cause, often related to shear pins, belts, or fuel supply.
Proper maintenance, using OEM parts for models SB410 and CMXGBAM1054541, minimizes these issues and ensures reliable winter operation.
Snowblower Won’t Start
If your Craftsman 24-inch snowblower fails to start, several factors could be at play. First, check the fuel level and ensure fresh gasoline is being used, especially after off-season storage. A clogged fuel line or carburetor can also prevent ignition.
Inspect the spark plug for fouling or damage, replacing it if necessary. Verify the spark plug wire is securely connected. Next, examine the recoil starter mechanism for proper function; a damaged pull cord or spring can hinder starting.
For models like 247.881732 or SB410, consult online diagrams and resources like eReplacementParts to locate and troubleshoot these components. Ensure the safety interlock switches are engaged correctly. Finally, a low oil level can trigger a safety shut-off, so check the oil level before attempting to restart.
Auger Not Engaging
When the auger on your Craftsman 24-inch snowblower isn’t engaging, a sheared shear pin is the most common culprit. These pins are designed to break upon encountering a significant obstruction, protecting the auger system.
Locate the shear pins – referencing parts diagrams for models like 247.888160 or 536887251 will be helpful – and inspect for breakage. Replacement is straightforward, but always use the correct size and type of pin.
Additionally, check the auger drive belt for wear or breakage. A loose or damaged belt won’t effectively transfer power to the auger. Resources like eReplacementParts offer guides for belt replacement. Ensure the auger engagement cable is properly connected and functioning smoothly. A disconnected or frayed cable will prevent engagement.
Drive System Problems
If your Craftsman 24-inch snowblower experiences drive system issues, several factors could be at play. Begin by inspecting the drive belt for wear, damage, or improper tension – parts diagrams (like those for model SB410) can aid in locating it.
A loose or broken belt prevents power from reaching the wheels. Next, check the drive engagement lever and cable; ensure they’re functioning correctly and aren’t obstructed. Refer to the owner’s manual (247.888160) for specific adjustment instructions.
Also, examine the wheel hubs and axles for damage or excessive play. Resources like eReplacementParts provide repair help and parts lists for models 247.881732 and 536887251, simplifying troubleshooting and repair.
Safety Precautions
Always perform pre-operation checks, referencing the 247.888160 manual. Ensure clear operation, avoiding bystanders, and proper storage for your Craftsman 24-inch snowblower.
Follow safe procedures, and review model-specific resources (536887251, SB410) for optimal winter safety and equipment longevity.
Pre-Operation Safety Checks
Before each use of your Craftsman 24-inch snowblower, thorough safety checks are paramount. Consult your owner’s manual, specifically referencing models like 247.888160, for detailed guidance. First, inspect the auger and impeller systems, ensuring they are free from obstructions and in good working order. Verify all bolts and fasteners are tightened securely to prevent unexpected component failure during operation.
Next, check the fuel and oil levels, adhering to the specifications outlined in the manual. Ensure the shear pins are in good condition and readily available for replacement. Confirm the drive system engages and disengages smoothly. Finally, inspect the discharge chute and ensure it can rotate freely and is securely locked in the desired position. Always clear the work area of obstacles, people, and pets before starting the snowblower. Remember, a proactive approach to safety prevents accidents and ensures reliable performance throughout the winter season.
Safe Operating Procedures
When operating your Craftsman 24-inch snowblower, prioritize safety at all times. Never operate the machine indoors or in enclosed spaces due to the risk of carbon monoxide poisoning. Always wear appropriate safety gear, including eye protection and sturdy footwear. Maintain a firm grip on the controls and walk at a safe, controlled pace. Avoid directing the discharge chute towards people, pets, or property.
Be mindful of hidden obstacles like ice patches or uneven terrain. Never attempt to clear a clogged chute with your hands; use a designated clearing tool. If the auger becomes jammed, shut off the engine and disconnect the spark plug before attempting to clear the blockage. Refer to your owner’s manual (models 247.881732, 536887251) for specific operating instructions and safety precautions. Remember, responsible operation ensures a safe and efficient snow removal experience.
Storage and Off-Season Care
Proper storage is crucial for maintaining your Craftsman 24-inch snowblower’s longevity. Before long-term storage, drain the fuel tank completely to prevent fuel deterioration and carburetor issues. Stabilize any remaining fuel in the system with a fuel stabilizer. Disconnect the spark plug wire to prevent accidental starting. Clean the snowblower thoroughly, removing any accumulated snow and ice.
Inspect belts and shear pins for wear and tear, replacing them as needed (refer to parts diagrams for models 247.888160, SB410). Store the snowblower in a dry, sheltered location, protecting it from the elements. Cover the machine to prevent dust accumulation. Consult your owner’s manual (including CMXGBAM1054541 support) for detailed off-season maintenance procedures, ensuring it’s ready for the next winter season.
Finding Replacement Parts
Locate genuine Craftsman snowblower parts through authorized retailers, utilizing model numbers like 247.888160 or SB410 for accurate ordering.
Choose between OEM parts and aftermarket options, referencing diagrams (model 247889571) for proper identification and fit, ensuring optimal performance.
Authorized Craftsman Parts Retailers
Securing genuine replacement parts for your Craftsman 24-inch snowblower is crucial for maintaining its performance and longevity. Several authorized retailers specialize in providing authentic components, ensuring a perfect fit and reliable operation. Sears remains a primary source, both online and through their physical stores, offering a comprehensive inventory of Craftsman parts.
Additionally, retailers like Amazon and eBay host authorized Craftsman parts sellers, providing convenient access and competitive pricing. However, always verify the seller’s credentials to guarantee authenticity. eReplacementParts.com is a dedicated online resource, offering detailed parts diagrams and expert assistance in identifying the correct components for models like 247.888160 and SB410.
Furthermore, local authorized service centers often stock common replacement parts and can provide professional guidance. When purchasing, always have your snowblower’s model number (e.g., 247889571, 536887251) readily available to ensure compatibility.
Using Model Numbers for Accurate Parts Ordering (247.888160, SB410)
Precise parts ordering for your Craftsman 24-inch snowblower hinges on utilizing the correct model number. Numbers like 247.888160 and SB410 uniquely identify your specific machine, ensuring compatibility with replacement components. Locate the model number on the snowblower’s frame, typically near the engine or auger housing.
When ordering from retailers like Sears, Amazon, or eReplacementParts.com, always input the full model number during your search. This prevents receiving incorrect parts that won’t fit or function properly. Even slight variations in model numbers can signify significant differences in components.
Resources such as online parts diagrams (for model 247889571) often require the model number for accurate identification. Confirming the number before purchase saves time, frustration, and ensures a successful repair for models like 536887251 and CMXGBAM1054541.
OEM vs. Aftermarket Parts
Choosing between Original Equipment Manufacturer (OEM) and aftermarket parts for your Craftsman 24-inch snowblower involves considering quality and cost. OEM parts, directly from Craftsman, guarantee a precise fit and are manufactured to the original specifications, ensuring optimal performance for models like 247.881732.
Aftermarket parts, produced by third-party manufacturers, are often more affordable but may vary in quality. While some aftermarket options are reliable, others might not meet the same standards as OEM components, potentially impacting the longevity of your snowblower (models SB410, 536887251).
For critical components like shear pins or auger parts, OEM is often recommended. However, for less crucial items, quality aftermarket alternatives can be a viable option. Always verify compatibility using the model number (247.888160, CMXGBAM1054541) before purchasing.
Specific Model Resources
Locating resources tailored to your specific Craftsman 24-inch snowblower model is crucial for effective maintenance and repair. Model numbers like 247.881732, 536887251, and CMXGBAM1054541 have dedicated support.
eReplacementParts provides model-specific diagrams and parts lists, while the Craftsman website offers owner’s manuals for models like 247.888160 and SB410.
Utilizing these resources ensures you have the correct information for your particular snowblower, simplifying troubleshooting and part replacement.
Resources for Model 247.881732
For Craftsman snowblower model 247.881732, a wealth of resources exists to support owners in maintaining optimal performance. eReplacementParts is a particularly valuable online destination, offering detailed parts diagrams specifically for this model, allowing for easy identification of components needing replacement.
Furthermore, this platform provides access to manuals and instructional videos, guiding users through repair procedures. Searching directly for “Craftsman 247.881732 parts” will yield numerous retailers offering OEM and aftermarket parts. Always verify compatibility before purchasing.
Owner’s manuals, often available for download from the Craftsman website, contain crucial safety information, maintenance schedules, and troubleshooting tips tailored to this specific 24-inch snowblower. Remember to utilize the model number when searching for assistance to ensure accuracy and relevance.
Resources for Model 536887251
Owners of the Craftsman snowblower, model 536887251, benefit from readily available support resources for maintenance and repair. Diagram-based parts lists, such as those found at various online retailers, simplify identifying the correct components for replacements, ensuring a proper fit and function.
eReplacementParts provides a comprehensive catalog of OEM parts specifically for this model, alongside symptom-based repair assistance and helpful instructional videos. Searching with the full model number guarantees accurate results and avoids compatibility issues.
Accessing the official Craftsman website allows downloading the owner’s manual, containing vital safety precautions, maintenance schedules, and troubleshooting guidance tailored to the 24-inch snowblower. Prompt access to these resources ensures efficient upkeep and prolonged lifespan.
CMXGBAM1054541 Support
Craftsman snowblower support for model CMXGBAM1054541 centers around providing accessible parts and repair information. Utilizing the model number when searching online retailers, like those offering OEM parts, is crucial for accurate component identification and ordering. Free shipping is often available on parts orders exceeding a certain amount, adding value for customers.
Finding product manuals and diagrams specifically for this model streamlines maintenance tasks. eReplacementParts offers detailed exploded views and symptom-based troubleshooting guides, empowering owners to address common issues independently.
Remember to prioritize safety by consulting the owner’s manual before undertaking any repairs. Proper maintenance, guided by these resources, ensures optimal performance and extends the lifespan of your 24-inch Craftsman snowblower.
